A Novel Preparation Method of Electrically Conductive Adhesives by Powder Spraying Process.

In a conventional electrically conductive adhesive (ECA) preparation process, typical ECAs are made by adding an appropriate amount of electrically conductive fillers, such as silver, into a polymer matrix, such as epoxy resin, to form a uniformly dispersed mixture by mixing and stirring operations. However, during the preparation process, secondary pollution and mass loss are caused by the vigorous mixture process. At the same time, the stirring operation introduces many small and stable bubbles, which affect the electrical conductivity of the ECAs. In light of these problems with the conventional preparation of ECAs, we developed a novel ECA preparation method that employs a powder spraying process: silver flakes are sprayed into the epoxy resin with a certain mass fraction to form formulated pastes. The as-prepared ECAs exhibited excellent properties compared with those prepared by the conventional process. This proves that the powder spraying process is feasible and superior to the conventional process.
