埃莱特拉的大分子晶体学:现状与未来展望。

Macromolecular crystallography at Elettra: current and future perspectives.

作者信息

Hegde Raghurama P, Demitri Nicola, Héroux Annie, Olivo Alessandro, Bais Giorgio, Cianci Michele, Storici Paola, Dumitrescu Dan George, Varshney Nishant Kumar, Gopal Balasubramanian, Sarma D D, Vaccari Lisa, Onesti Silvia, Polentarutti Maurizio

机构信息

Elettra - Sincrotrone Trieste SCpA, SS 14 km 163,5 in AREA Science Park, Basovizza, 34149 Trieste, Italy.

Former Elettra - Sincrotrone Trieste SCpA, SS 14 km 163,5 in AREA Science Park, Basovizza, 34149 Trieste, Italy.

出版信息

J Synchrotron Radiat. 2025 May 1;32(Pt 3):757-765. doi: 10.1107/S1600577525001055. Epub 2025 Mar 26.

Abstract

The Elettra synchrotron radiation facility, located in Trieste, Italy, is a third-generation storage ring, operating in top-up mode at both 2.0 and 2.4 GeV. The facility currently hosts one beamline fully dedicated to macromolecular crystallography, XRD2. XRD2 is based on a superconducting wiggler, and it has been open to users since 2018. On-site and remote access for data collection, as well as monitoring tools and automatic data analysis pipelines are available to its users. In addition, since 1994 Elettra has operated a general-purpose diffraction beamline, XRD1, offering the macromolecular community a wide spectrum extending to long wavelengths for phasing and ion identification. Ancillary facilities support the beamlines, providing sample preparation and a high-throughput crystallization platform for the user community. A new CryoEM facility is being established on campus and jointly operated by the Consiglio Nazionale della Ricerche - Istituto Officina dei Materiali (CNR-IOM) and Elettra, providing further opportunities to the Elettra user community. This review outlines the current capabilities and anticipated developments for macromolecular crystallography at Elettra to accompany the upcoming upgrade to Elettra 2.0, featuring a six-bend enhanced achromat lattice. The new source is expected to deliver a high-brilliance beam, enabling the macromolecular crystallography community to better address the emerging and future scientific challenges.

摘要

位于意大利的里雅斯特的埃莱特拉同步辐射装置是一座第三代储存环,以2.0GeV和2.4GeV的能量在满能量注入模式下运行。该装置目前有一条完全 dedicated 于大分子晶体学的光束线XRD2。XRD2基于一个超导摆动器,自2018年起对用户开放。其用户可以使用现场和远程数据采集方式,以及监测工具和自动数据分析管道。此外,自1994年以来,埃莱特拉还运行着一条通用衍射光束线XRD1,为大分子研究群体提供了一个延伸至长波长的广泛光谱,用于相位测定和离子识别。辅助设施支持这些光束线,为用户群体提供样品制备和高通量结晶平台。校园内正在建立一个新的低温电子显微镜设施,由意大利国家研究委员会 - 材料应用研究所(CNR - IOM)和埃莱特拉联合运营,为埃莱特拉用户群体提供更多机会。本综述概述了埃莱特拉大分子晶体学的当前能力和预期发展,以配合即将进行的升级到具有六弯增强消色差晶格的埃莱特拉2.0。新光源预计将提供高亮度光束,使大分子晶体学研究群体能够更好地应对新出现的和未来的科学挑战。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/733b/12067329/f3a605f58709/s-32-00757-fig1.jpg
